TX150 S8 / TX200 S7
Upgrade and Maintenance Manual 367
System board and components
Ê Select the Advanced menu.
Ê Select the Trusted Computing submenu.
Ê Set the TPM Support and TPM State settings to Disabled.
Ê Save your changes and exit the BIOS.
I For detailed information on how to access the BIOS and modify
settings, refer to the corresponding BIOS Setup Utility reference
manual.
Ê "Locating the defective server" on page 47
Ê "Shutting down the server" on page 50
Ê "Disconnecting the server from the mains" on page 50
Ê "Getting access to the component" on page 51
Ê "Removing the system fan holder" on page 76
14.4.2.2 Removing the TPM
Ê "Removing the defective system board" on page 377
Ê Lay the system board on a soft, antistatic surface with its component side
facing down.
Figure 281: Removing the TPM screw
Ê Locate the slotted lower end of the TPM screw (1).
