354 Upgrade and Maintenance Manual

TX150 S8 / TX200 S7

System board and components

14.3.1.2 Installing the UFM

Figure 266: UFM kit

Figure 267: UFM mounting location

1 USB Flash Module (UFM) 2 UFM spacer

3 UFM nylon screw
