TX150 S8 / TX200 S7
Upgrade and Maintenance Manual 429
17.4 Minimum startup configuration
If the server does not start up or other problems occur, it may be necessary to
take the system down to its most basic configuration in order to isolate the
defective component.
The minimum startup configuration consists of the following components and
cables:
Ê "Shutting down the server" on page 50
Ê "Disconnecting the server from the mains" on page 50
WP
Default (no
jumper)
BIOS Write Protect disabled
BIOS Write
Protect enabled
BIOS Write Protect enabled
Field Replaceable Units (FRU)
Component Notes and reference
System board no TPM, UFM or expansion cards installed
1 CPU with CPU heat sink installed in socket CPU 1
1 memory module installed in DIMM slot 1A
Front panel module without connected front LAN module
1 Power supply module installed in PSU bay 1
Table 6: Minimum startup configuration - components
Cable Notes and reference
Front panel cable
Power cable
Table 7: Minimum startup configuration - cables
Jumper Setting Description
