238 Upgrade and Maintenance Manual
TX150 S8 / TX200 S7
Expansion cards and backup units
9.5.5.3 Disconnecting the FBU cable from the FBU
Figure 165: Disconnecting the FBU cable from the FBU
Ê Disconnect the FBU cable from the FBU.
9.5.5.4 Removing the FBU from the holder
Figure 166: Removing the FBU from the holder
Ê Pull the FBU at a slight angle out of the holder.
