TX150 S8 / TX200 S7
Upgrade and Maintenance Manual 279
Accessible drives and LSD
12.2 Installing accessible drives
12.2.1 Preliminary steps
Ê "Shutting down the server" on page 50
Ê "Disconnecting the server from the mains" on page 50
Ê "Getting access to the component" on page 51
I The front cover only needs to be removed in order to remove or install
accessible drive dummy covers.
Ê "Removing the system fan holder" on page 76
12.2.2 Removing accessible drive dummy covers
Ê If applicable, remove the accessible dummy covers for the desired
accessible drive bay as described in section "Removing accessible drive
dummy covers" on page 173.
12.2.3 Installing mounting brackets to RDX and DAT72
backup drives
This section is not applied for Japanese market.
Backup drive mounting brackets are contained in mounting kit S26361-F3753-
E1 (to be ordered separately with the backup drive).
I No new mounting brackets are available when replacing a backup drive
during service.
Ê If applicable, remove existing mounting brackets from the backup drive.
Upgrade and Repair Unit
(URU)
Hardware: 10 minutes
Tools: Slotted screw driver (for bending in or out accessible drive mounting
brackets)
