TX150 S8 / TX200 S7 Upgrade and Maintenance Manual 169
Hard disk drives / solid state drives
7.4 HDD extension boxes
I The procedures for the HDD extension boxes are identic except of
cabling and required bays.
7.4.1 HDD extension box variants
8x 2.5-inch HDD extension box
Figure 97: 8x 2.5-inch HDD extension box - Rack version
Figure 98: 8x 2.5-inch HDD extension box - Tower version
I The 8x 2.5-inch HDD extension box occupies accessible drive bays 2
and 3.
Bays 2+3
Bays 2+3
