78 Upgrade and Maintenance Manual
TX150 S8 / TX200 S7
Basic hardware procedures
4.10 Handling rubber feet
Figure 33: Handling the rubber feet
Removing rubber feet
Ê Lay the server on its right-hand side.
I At least two people are needed to turn over a fully equipped server.
Remove hard disk drives and power supply modules in order to
facilitate the task.
Ê Using a slotted screw driver, slightly pry up on each rubber foot until it
detaches.
Installing rubber feet
Ê Push in each rubber foot.
Ê Bring the server back to its vertical position.
