344 Upgrade and Maintenance Manual
TX150 S8 / TX200 S7
Front panel and external connectors
After removing the LAN cable from the front management LAN
connector, the iRMC S3 will immediately become accessible via the
rear management LAN connector again.
Ê Accessing the iRMC S3 using the front management LAN connector is only
possible via the preset IP address 192.168.1.1 and cannot be configured
otherwise.
Configure your client computer to use any static IP address on subnet
192.168.1.x (except 192.168.1.1) with subnet mask 255.255.255.0.
13.2.2 Removing the front LAN connector
13.2.2.1 Preliminary steps
Ê "Disabling or suspending BitLocker functionality" on page 79
Ê "Locating the defective server" on page 47
Ê "Shutting down the server" on page 50
Ê "Disconnecting the server from the mains" on page 50
Ê "Getting access to the component" on page 51
Ê "Removing the system fan holder" on page 76
13.2.2.2 Removing the front LAN connector
Ê Disconnect the front panel cables from the system board as described in
section "Disconnecting cables" on page 329.
Ê Remove the front panel module from the chassis as described in section
"Removing the front panel module" on page 331.
Ê Remove the front panel module cover from the front panel frame as
described in section "Removing the front panel module cover" on page 334.
Upgrade and Repair Unit
(URU)
Hardware: 10 minutes
Tools: tool-less
