404 Upgrade and Maintenance Manual
TX150 S8 / TX200 S7
C21 CBL_SAS36TO36 Y3963-V117 SAS backplane to SAS controller
C22 CBL_BBU08 160 Y3987-V3 BBU to SAS controller
C22 CBL_FBU 170 Y4032-V3 FBU to TFM
C23 CBL_DVD Y3928-V205 System board to DVD
C24 CBL_SAS BOX 2x3,5 Y3963-V203 To 2x 3.5 HDD extension box
C32 CBL_SATA_Full_Pow 410 Y3930-V601
C33 CBL_SATA_Slim_Pow 400 Y3986-V302
C34 CBL_SAS_Dev_PowSig 700 Y3969-V401
C35 CBL_PATA_Dev_Pow 410 Y4029-V1
C36 cbl_USB (USB 2.0) Y3973-V96 USB backup drive to system board
C37 USB 3.0 cable Y4039-V80
USB backup drive to USB3.0
interface card
CBL_LTO Y3969-V202
No. Name
Part number
(T26139-)
Routing
Table 5: List of used cables
