TX150 S8 / TX200 S7

Upgrade and Maintenance Manual 187

Fans

Fan numbering

Refer to the below figure for the fan numbering scheme in ServerView

Operations Manager:

Figure 115: Fan numbering

System fans 1 -3 in the system fan holder2

4 Rear fan
