416 Upgrade and Maintenance Manual TX150 S8 / TX200 S7
Appendix
3.5-inch HDD model
Figure 328: PRIMERGY TX200 S7 front - 3.5-inch HDD model
1
3.5-inch hard disk drives /
dummy modules
5
Local service display module
(LSD)
2ID card 6
Backup drive /
5.25-inch dummy module
3
2x 3.5-inch HDD extension box
with LSD and slimline ODD
bays
7
Front panel module:
Front Management LAN
connector (optional)
4 Optical disk drive 8
Front panel module: 2 USB
connectors
