TX150 S8 / TX200 S7
Upgrade and Maintenance Manual 199
Expansion cards and backup units
Figure 123: Expansion card slot sequence
I For the latest information on supported expansion cards, refer to your
server’s hardware configurator available online at the following address:
for the global market:
http://ts.fujitsu.com/products/standard_servers/tower/primergy_tx200s7.html
http://ts.fujitsu.com/products/standard_servers/tower/primergy_tx150s8.html
for the Japanese market:
http://jp.fujitsu.com/platform/server/primergy/system/
TX200 S7
PCI 32/33 PCIe x4 PCIe x4 PCIe x16 PCIe x4 PCIe x16
PCH PCH CPU1 CPU1 CPU1 CPU2
Rule # PCI Controller max. # Slot1 Slot2 Slot3 Slot4 Slot5 Slot6
1 SAS/Raid Lynx2 D2607 (2) 2 - 2 - - 1 -
2 SAS/Raid Cougar2 D2616 2 - 2 - - 1 -
3
SAS/Raid Cougar3
D3116-B14/-B25 (Gen2)
2- 2 - - 1 -
4 LAN 10GE Dual Niantic D2755 1 - - - 1 3 2
5 LAN 2x10GBase-T X540-T2 2 - - - 1 3 2
6 LPe16002 (1) 2 - 5 4 1 3 2
7 LPe12002 (1) 2 - 5 4 1 3 2
8 QLE2562 (1) 2 - 5 4 1 3 2
9 LPe16000 (1) 2 - 3 2 4 1 5
10 LPe1250 (1) 2 - 3 2 4 1 5
11 QLE2560 (1) 2 - 3 2 4 1 5
12 NVS300 (PCIe x1) 1 - 1 3 - 2 -
13 USB3.0 (PCIe x1) 1 - 1 2 - - -
14 LSI SAS 9280-8e WASAT 2 - 1 - 3 2 4
15 LSI SAS 9285CV8e Procyon-U 1 - - - 2 1 3
16 SAS Tape Ctrl. (LSI 9200-8e) 2 - 3 2 4 1 5
17 1GbE CT Desktop 4 - 3 2 4 1 5
18 1GbE Quad D2745 2 - 3 2 4 1 5
19 1GbE Quad D3045 2 - 3 2 4 1 5
20 1GbE Dual D2735 2 - 3 2 4 1 5
21 1GbE Dual D3035 2 - 3 2 4 1 5
22 1GbE PRO/1000 PF LC 4 - 3 2 4 1 5
Order of Install Priority (1…n)
TX150 S8
PCI 32/33 PCIe x4 PCIe x4 PCIe x16 PCIe x4 PCIe x1
PCH PCH CPU1 CPU1 CPU1 PCH
Rule # PCI Controller max. # Slot1 Slot2 Slot3 Slot4 Slot5 Slot6
1 SAS/Raid Lynx2 D2607 (2) 2 - 2 - - 1 -
2 SAS/Raid Cougar2 D2616 2 - 2 - - 1 -
3
SAS/Raid Cougar3
D3116-B14/-B25 (Gen2)
2- 2 - - 1 -
4 LAN 10GE Dual Niantic D2755 1 - - 3 1 2 -
5 LAN 2x10GBase-T X540-T2 1 - - 3 1 2 -
6 LP12002/QLE 2562 2 - - - - - -
7 LP1250 / QLE2560 2 - - - - - -
8 NVS300 (PCIe x1) 1 - - 3 - 2 1
9 USB3.0 (PCIe x1) 1 - - 2 3 - 1
10 LSI SAS 9280-8e WASAT 2 - 1 - 3 2 -
11 SAS Tape Ctrl. (LSI 9200-8e) 2 - 3 2 4 1 -
12 1GbE CT Desktop 4 - 4 2 5 3 1
13 1GbE Quad D2745 2 - 3 2 4 1 5
14 1GbE Quad D3045 2 - 3 2 4 1 5
15 1GbE Dual D2735 2 - 3 2 4 1 5
16 1GbE Dual D3035 2 - 3 2 4 1 5
17 1GbE PRO/1000 PF LC 4 - 3 2 4 1 5
Order of Install Priority (1…n)
(1) mix of FC Controller QLogic with Emulex is not released
(2) option ROM of each Lynx2 Controller is requested to be enabled!
