324 Upgrade and Maintenance Manual

TX150 S8 / TX200 S7

Accessible drives and LSD

Figure 243: Removing the mounting frame from the slimline ODD

Ê Remove the slimline ODD mounting bracket from the slimline ODD.

Figure 244: Reinstalling the slimline ODD mounting frame on the HDD expansion box
