HP Designjet Z Series GP Photo Printers — Service Manual 5-3
Parts and Diagrams - Printer Support
Printer Support
Reference
on
Figure
HP Part
Number
Part Description Printer
Model
Size
Page
a
a Refers to the page in the Removal and Installation Chapter
1 Q5669-60718 Leg Cover All All N/A
2 Q5669-60716 Legs Assembly All All N/A
3 Q5669-60715
Foot Assembly (includes 1 foot and
1 support tube)
All All N/A
4
Q5669-60719
Bin Assembly (Includes the Bin
Support)
All
24 inch N/A
Q6659-60237 44 inch N/A
5
Q5669-60717
X-Brace Assembly All
24 inch N/A
Q6659-60236 44 inch N/A
- Q5669-60730
Hardware Kit (Includes screws for
Legs Assembly)
All All N/A
- Q5669-67063 Basket Tubes and Adaptors All All N/A
