HP DesignJet Z2100

HP Designjet Z Series GP Photo Printers — Service Manual 5-21
Parts and Diagrams - Paper Path Assemblies (Front)
Paper Path Assemblies (Front)
Reference
on
Figure
HP Part
Number
Part Description Printer
Model
Size
Page
a
a Refers to the page in the Removal and Installation Chapter
1
Q6718-67014 Starwheel Assembly (without
Actuator)
All 24 inch
6-166
Q6719-67004 All 44 inch
1
Q5669-67061
Starwheel Assembly (with Actuator)
Z2100/
Z3100/
Z3100ps
24 inch
6-166
Q6659-67016 44 inch
2
Q6675-60042
Print Zone Overdrive All
24 inch
6-171
Q6677-60018 44 inch
3
Q5669-67054
Starwheel Lifter
Z2100/
Z3100/
Z3100ps
All 6-205
Q6718-67013
Z3200/
Z3200ps
4 Q5669-60713 Cutter Assembly All All 6-43
5
Q5669-60701
Full Bleed Foam Kit All
24 inch
6-214
Q6659-60182 44 inch
