6-12 Designjet Z Series — Service Manual
Removal and Installation
Performing the Service Calibrations and Diagnostic Tests
When you are ready to perform the service calibrations and diagnostic tests that correspond to the
component you have installed or replaced, consult the following page numbers for procedures:
PRS Test - Refer to Page 3-9.
Scan Axis Test - Refer to Page 3-11.
Cutter test - Refer to Page 3-16.
Star Wheel Lifter test - Refer to Page 3-7.
2. Paper Drive - Refer to Page 3-18.
3. Electronics Module - Refer to Page 3-22.
4. Carriage Assembly - Refer to Page 3-27.
5. Sensors - Refer to Page 3-33.
6. Color Sensor ESP (spectrophotometer) - Refer to Page 3-36.
7. Ink Delivery System (IDS) - Refer to Page 3-38.
8. Service Station - Refer to Page 3-45.
Paper Advance Calibration - Refer to Page 4-6.
Drop Detector Calibration - Refer to Page 4-12.
Line Sensor Calibration - Refer to Page 4-15.
4. Reset Life Counters - Refer to Page 3-66. (after replacement only)
