Designjet Z Series — Service Manual 2-15
System Error Codes - Full Descriptions
System Error: 47:03
Problem
Description:
Star wheels motor error.
Corrective Action: Try the following:
Same as 47:YZ. The error is continuable, but only if it happens from time
to time.
System Error: 47:YZ
Problem
Description:
Star wheels motor error..
Corrective Action: Try the following:
Switch the Power OFF from the back of the Printer and disconnect the
Power cord. Reconnect the power cord and power On the Printer.
Check that the Starwheel Assembly cable is not damaged and is correctly
connected to Main PCA.
Open the Window and check for any visible obstacles restricting the
movement of the Starwheel Assembly, then clear the obstruction.
Perform the Scan Axis Starwheel diagnostic test to troubleshoot the
problem further
Page 3-7.
Replace the Starwheel Motor Page 6-212.
Replace the Starwheel Lifter Page 6-201 and Page 6-208.
If the System Error continues, replace the Main PCA Page 6-163.
System Error: 48:YZ
Problem
Description:
PPS system failure.
Corrective Action: Try the following:
Switch the Power OFF from the back of the Printer and disconnect the
Power cord. Reconnect the power cord and power On the Printer.
Check that the Pen to Paper Space (PPS) Solenoid cable is not damaged
and is correctly connected to the PrintMech PCA.
Perform the Scan Axis PSS diagnostic test to troubleshoot the problem
further
Page 3-9.
Make sure the Service Station is correctly installed. Sometimes, if the
Service Station is not correctly installed, the front of the Service Station
falls down (causing the Service Station to be tilted), and the L-Bracket
support does not fit properly. The front of the Service Station should be
“UP,” and the L-Bracket should fit well with the Service Station.
Replace the Pen to Paper Space (PPS) Solenoid Page 6-73.
If the System Error continues, replace the PrintMech PCA Page 6-71.
System Error: 51:YZ
Problem
Description:
Window Sensor failure.
Corrective Action: Try the following:
