Designjet Z Series — Service Manual 1-55
Ink Supplies Troubleshooting
Ink Supplies Troubleshooting
Introduction to Ink Supplies
What are Ink Supplies?
For each of the ink colors used in the printer, there are two components, the
Printhead and Ink Cartridge. These components are called Ink Supplies.
Ink Cartridges
The printer's Ink Cartridges provide ink to the Printheads. The color Ink
Cartridges supplied with the printer have a capacity of 69ml but optional
130 ml cartridges are also available
.
The Ink Cartridges for the Z2100/Z3100 Photo Printer series require no
maintenance or cleaning. As long as each Ink Cartridge is inserted correctly
into its slot, the ink will flow to the Printheads. Because the Printheads control
the amount of ink transferred to the page, you will continue to see high-
quality printing results even when the ink levels are getting low.
All these Ink cartridges are physically the same size. Only
the internal capacity varies.
