Designjet Z Series — Service Manual 6-3
Removal and Installation - Introduction
Required Tools
All the special tools and equipment required to disassemble, service and repair the Printer are
provided in the Toolkit P/N . Some tools can be ordered seperately from the toolkit.
Refer to Page 5-
25.
The Toolkit contains the following tools:
You will also need the following standard hand tools:
Toolkit P/N
Description/Comments HP Part Number
Spanner 13 mm Q6675-67011
Alcohol Q6675-60070
Allen Key #2 Q6675-60041
Cleaning Cloth 9300-2531
Cleaning Sponge/Bag Assembly C6071- 60218
Flex Contacts Cleaning Support Q1271- 60754
Lubricant Oil Q6675-60061
Isopropyl Alcohol Q6675-60091
Media Driver Adjustment Tool Q6675-67009
Handle for Media Driver Tool Support Q6675-67010
Oil Dispenser Q6675-60062
Pinchwheel Alignment Tool Q5669-20595
Pinchwheel Insertion Tool Q5669-20594
Protective Plastic Gloves Q6675-60035
T-15 Screwdriver 8710-2456
Tweezers Q6675-60037
Standard Tool Requirements
Description/Comments Size
Long Torx Screwdriver 1/4 inch drive
Torx Bit (75 mm) 8
10
15
20
Philips Screwdriver 1
Pliers N/A
Snips N/A
Pipe Spanner 5.5 mm
Flat Bladed Screwdriver N/A
