Designjet Z Series — Service Manual 3-61
Service Utilities
1. Turn Drive Roller
The purpose of this Service Utility is to rotate the Drive Roller and the
Overdrive in order to clean them.
Perform the Turn Drive Roller utility as follows:
1 In the Service Utilities submenu, scroll to Turn Drive Roller and press OK.
If the printer is not used for 135 seconds, the printer exits
out of the Service Utilities Menu and you must repeat the
above steps to enter Service Utilities again.
In some cases a quick press of a button may not be
recognized by the Printer. When pressing a button, be sure
to press it deliberately and all the way to the bottom of its
travel.
REMOVE THE MEDIA BEFORE PERFORMING THIS OPERATION.
OPEN THE WINDOW OF THE PRINTER AND ACTIVATE THE
WINDOW SENSOR (USE A PIECE OF PAPER TO COVER THE
SENSOR) BEFORE PERFORMING THIS SERVICE UTILITY.
