HP DesignJet Z2100 - Right Ink Supply Station; Removal

Designjet Z Series — Service Manual 6-143
Removal and Installation - Right Ink Supply Station
Right Ink Supply Station
Removal
1. Remove the Right Cover (refer to page 6-
27).
2. Remove two T-10 screws that secure the
Right Side Plate of the Ink Supply Station.
3. Remove the Right Side Plate of the Right Ink
Supply Station.
4. Remove two T-10 screws that secure the Left
Side Plate of the Right Ink Supply Station.
Switch off the printer and remove the power cable.
