Preventive Maintenance
7-6 Designjet Z Series — Service Manual
Z3200/Z3200ps (24 inch) P/N Q6718-67011:
Z3200/Z3200ps (44 inch) P/N Q6719-67002:
After replacing a preventive maintenance kit, make sure to reset the relevant
life counter. For the Reset Life Counters procedure, refer to page
3-66.
Preventive Maintenance Kit #2
The Preventive Maintenance Kit #2 is available in the following different
versions
:
All versions (24 inch/44 inch) P/N Q6718-67026
After replacing a preventive maintenance kit, make sure to reset the relevant
life counter. For the Reset Life Counters procedure, refer to page
3-66.
Preventive Maintenance Kit #3
The Preventive Maintenance Kit #3 is available in the following different
versions:
Part Number Description
Q6718-67012 Carriage Assy 24 inch
Q5669-60681 Trailing Cable
Q6718-67002 Ink Supply Tubes 24 inch
Q5669-60673 Belt 24 SV
Q5669-60674 Scan Axis Motor SV
Q5669-60692 Lubrification Kit SV
Part Number Description
Q6719-67003 Carriage Assy 44 inch
Q6659-60177 Trailing Cable
Q6719-67001 Ink Supply Tubes 44 inch
Q6659-60175 Belt 44 SV
Q5669-60674 Scan Axis Motor SV
Q5669-60692 Lubrification Kit SV
Part Number Description
Q6718-67025 Service Station
Q5669-67049 Left spittoon
