Designjet Z Series — Service Manual 7-3
Preventive Maintenance
2 Use an Oil Dispenser (Q6675-60062) to lubricate the Carriage Rail and the
Carriage Slider Rod.
3 Replace the Carriage Rail Oiler (refer to page 5-120) with the new one
contained in the kit and add 2-3 drops of oil to the foam of the Carriage Rail
Oiler.
4 Use an Oil Dispenser (Q6675-60062) to lubricate the Carriage Rear
Bushing.
General Cleaning
Proper general cleaning should include the following:
1 Blow away dust accumulation with compressed air if available.
2 Clean the outer surface of the Printer with a damp sponge or cloth. Use a
mild soap and water solution if necessary. Do not use abrasive cleaners.
3 Wipe the Printer dry with a soft lint-free cloth.
Cleaning the Drive Roller and Overdrive
1 Perform the Turn Drive Roller Utility (Refer to Page 3-61).
2
Open the window and apply any common household cleaning solution
(water based only) to a soft, lint-free rag and apply it to the Drive Roller and
Overdrive surface while it is rotating. Make sure that you thoroughly clean the
Drive Roller and Overdrive surface.
3 Press Enter when you have completed the cleaning procedure.
4 Allow the Drive Roller to dry before loading media in to the Printer.
Level of Printer Usage
Normal printer use means 6,000,000 Carriage Cycles (which corresponds
to approximately 100,000 A0 prints on average). Under normal usage
conditions, it will be approximately 5 years before the printer needs
maintenance. If the printer is used more than the normal usage conditions,
then it will need maintenance service much more frequently.
To prevent an electric shock, make sure that the Printer is
switched OFF and unplugged before any cleaning is
performed. Do NOT let any water get inside the Printer.
If ink is spilled on the Overdrive, remove the ink
immediately. Due to the ink's reflectance, ink on the
Overdrive can disrupt the Printer's edge-sensing function.
To remove any ink from the Overdrive, perform the
following procedure:
Prevent water or other liquids from running onto electrical
components or circuits, or through openings in the
Electronics Module.
