Parts and Diagrams - Center Covers (Front)
Center Covers (Front)
Reference
on
Figure
HP Part
Number
Part Description Printer
Model
Size
Page
a
a Refers to the page in the Removal and Installation Chapter
1
Q5669-60662
Window All
24 inch
6-13
Q6659-60172 44 inch
2
Q5669-60656
Top Cover All
24 inch
Q6659-60168 44 inch
3 Q5669-60675 Window Position Sensor All All 6-54
4
Q5669-60155
Media Output Assembly All
24 inch
6-18
Q6659-60089 44 inch
5
Q5669-60651
Front Cover
Z2100
24 inch
6-17
Q6659-60165 44 inch
Q5669-67001 Z3100/
Z3100ps
/Z3200/
Z3200ps
24 inch
Q6659-67001 44 inch
6
Q6675-60060
Front Panel
Z2100
All 6-48
Q5669-60714
Z3100/
Z3100ps
Q6718-67010
Z3200/
Z3200ps
