HP DesignJet Z2100

HP Designjet Z Series GP Photo Printers — Service Manual 5-13
Parts and Diagrams - Right Hand Assemblies
Right Hand Assemblies
Reference
on
Figure
HP Part
Number
Part Description Printer
Model
Size
Page
a
a Refers to the page in the Removal and Installation Chapter
1 Q6675-60043 Carriage Rail Oiler All All 6-120
2 Q5669-67807 Pen to Paper Space (PPS) Solenoid All All 6-73
3 Q5669-60674 Scan-Axis Motor All All 6-116
4 Q6675-60018 PrintMech PCA All All 6-71
5 Q5669-60667 Service Station Spittoon All All 6-60
6 Q5669-60664 Aerosol Fan Assembly All All 6-65
7 Q6718-67025 Service Station All All 6-60
8 Q5669-60666 Drop Detector All All 6-64
9
Q6675-60020
Right Ink Supply Station
Z2100
All 6-143
Q5669-60670
Z3100/
Z3100ps
Q6718-67001
Z3200/
Z3200ps
