HP DesignJet Z2100

HP Designjet Z Series GP Photo Printers — Service Manual 5-17
Parts and Diagrams - Carriage Assembly
Carriage Assembly
Reference
on
Figure
HP Part
Number
Part Description Printer
Model
Size
Page
a
a Refers to the page in the Removal and Installation Chapter
1 Q5669-60689 Carriage PCA Cover All All 6-138
2 Q5669-60685 Carriage Latch All All 6-133
3 Q5669-60686
Carriage Cover (includes Carriage
Latch)
All All 6-133
4
Q5669-60682
Carriage PCA
Z2100/
Z3100/
Z3100ps
All
6-138
Q6718-67003
Z3200/
Z3200ps
44 inch
5 Q5669-60687 Carriage Rear Bushing All All 6-113
6 Q6683-67004 Line Sensor All All 6-128
7 Q5669-60684
Color Sensor ESP
(spectrophotometer)
All All 6-122
8
Q5669-67052
Trailing Cable All
24 inch
6-92
Q6659-67015 44 inch
1 - 8
Q6675-67020
Carriage Assembly (includes: Line
Sensor, Carriage Cover, Carriage
Latch, Carriage PCA, Carriage
Rear Bushing, Trailing Cable, and
Color Sensor (ESP)
Z2100 24 inch
6-100
Q6677-67004 Z2100 44 inch
Q5669-67051
Z3100/
Z3100ps
24 inch
Q6659-67014
Z3100/
Z3100ps
44 inch
Q6718-67012
Z3200/
Z3200ps
24 inch
Q6719-67003 44 inch
Q5669-67055 Extra High PRS Wedge All All 6-109
