HP DesignJet Z2100

HP Designjet Z Series GP Photo Printers — Service Manual 5-15
Parts and Diagrams - Left Hand Assemblies
Left Hand Assemblies
Ref HP Part
Number
Part Description Printer Model Size Page
1
Q6675-60019
Left Ink Supply Station
Z2100
All 6-147
Q5669-60669
Z3100/Z3100ps
/Z3200/
Z3200ps
2 Q6708-67017 Starwheel Motor All All 6-212
3 Q5669-60703 Encoder Sensor All All 6-178
4 Q5669-60702 Encoder Disk All All 6-178
5 Q5669-60700 Media Advance Transmission All All 6-181
6 Q5669-67049 Left Spittoon All All 6-175
7
Q5669-60693
Power Supply Unit (PSU) Assembly
Z2100Z3100/
Z3100ps
All 6-163
Q 6718 -670 05
Z3200/
Z3200ps
8
Q6677-67007
Main PCA with Power Supply Unit
(PSU) Assembly
Z2100 Rev C
Z3100,
Z3100ps
All
6-163
Q6718-67029
Z3200 Rev. A
Z3200ps
Rev. A
All
Q677-67008 Z2100 Rev. D All
Q6719-67009
Z3200 Rev. B
Z3200ps
Rev. B
All
9
Q6675-67029
Formatter with HDD
Z2100
Rev. C
All 6-159
Q5669-60175 Z3100
Q5670-67001 Z3100ps
Q6718-60047
Z3200 Rev. A
Z3200ps Rev. A
9a CK837-67026 Formatter without HDD
Z2100 Rev. D
Z3200 Rev. B
Z3200ps
Rev. B
All
9b
Q6677-67009
Hard Disk Drive
Z2100 Rev. D All
Q6719-67010
Z3200 Rev. B
Z3200ps Rev. B
All
10 Q5669-60705 Media Lever All All 6-38
11 Q5669-60706 Media Lever Position Sensor All All 6-41
