Service Tests and Utilities
3-38 Designjet Z Series — Service Manual
9 The Front Panel then prompts you load media:
10 Raise the Media Lever.
11 Load media.
12 Lower the Media Lever.
13 Press any key to continue.
14 The Front Panel then displays the DeltaE test result and prompts you to press
any key to continue.
15 Press any key to continue.
16 The Front Panel shows the test complete display for a few seconds.
17 The Front Panel prompts you to shutdown the printer to complete the test.
18 Press any key to shutdown the printer.
7. Ink Delivery System (IDS)
The complete Ink Delivery System test consists of individual tests for the
different components related to this subsystem. These tests are:
Ink Delivery System
Check Ink Supplies
Check Leakage
