HP DesignJet Z2100

HP Designjet Z Series GP Photo Printers — Service Manual 5-19
Parts and Diagrams - Scan-Axis Assemblies
Scan-Axis Assemblies
Reference
on
Figure
HP Part
Number
Part Description Printer
Model
Size
Page
a
a Refers to the page in the Removal and Installation Chapter
1
Q6675-60021
Ink Supply Tubes
Z2100
24 inch
6-151
Q5669-60671
Z3100/
Z3100ps
Q6677-60007 Z2100
44 inch
Q6659-60174
Z3100/
Z3100ps
Q6718-67002
Z3200/
Z3200ps
24 inch
Q6719-67001 44 inch
2
Q6675-60071
Encoder Strip (including Encoder
Strip Spring and Nut)
All
24 inch
6-84
Q6677-60024 44 inch
3
Q5669-60673
Belt Assembly All
24 inch
6-115
Q6659-60175 44 inch
4 Q5669-60672 Belt Tensioner All All 6-115
5
Q5669-67052
Trailing Cable (with Carriage PCA
Cover)
All
24 inch
6-92
Q6659-67015 44 inch
-
Q5669-60679
Encoder Strip (including Encoder
Strip Spring and Nut) - 50 units
All
24 inch
6-84
Q6659-60176 44 inch
