Preventive Maintenance
7-4 Designjet Z Series — Service Manual
One of the EEROM counters is assigned to counting the number of carriage
cycles.
When these components of the Printer exceed this amount, the front panel
displays the following message:
"Maintenance #1 required"
"Maintenance #2 required”
"Maintenance #3 required”
Once one of the maintenance advised messages is displayed, the relevant
preventive maintenance kit must be used to replace the most worn parts of
the printer. Use the Removal and Installation Chapter of this Service Manual
as a guide to replace the necessary parts.
Service Part LIFE_VALUE Maintenance
Advice
Belt Cycles 6000000 PMKIT1
Bushings Life 3000000 PMKIT1
Trailing Cable Cycles 3000000 PMKIT1
Scan Axis Cycles 6000000 PMKIT1
Scan Axis Distance Covered 4500000 PMKIT1
Tubes Cycles 6500000 PMKIT1
Service Station Life 450000000 PMKIT2
Left Spittoon Volume 51000000 PMKIT2
Cutter Life 25000 PMKIT3
