6-70 Designjet Z Series — Service Manual
Removal and Installation
12. Lower the Primer Assembly to disengage
the top attachment lugs.
13. Remove the Primer Assembly from the
Service Station.
When you install the Primer Assembly make sure you connect the three
primer tubes in accordance with their identification markings.
When you finish installing or replacing this component, you must perform the
necessary Service Calibrations. To find which calibrations you must perform,
Refer to page 6-8,
Service Calibration Guide to Removal and Installation
.
