Designjet Z Series — Service Manual 6-137
Removal and Installation - Carriage Cover (includes Carriage Latch)
18. Carefully lift the Carriage Cover in the
vertical position to remove it from the
Carriage Assembly.
When you finish installing or replacing this component, you must perform the
necessary Service Calibrations. To find which calibrations you must perform,
Refer to page 6-8,
Service Calibration Guide to Removal and Installation
.
