6-154 Designjet Z Series — Service Manual
Removal and Installation
13. Carefully lift the Ink Supply Tubes guide
enough until you can slide it forwards out
of the printer.
14. Gently move the Ink Supply Tubes from the
printer.
15. Use a flat bladed screwdriver to release all
the Ink Supply Tubes clamps from the
printer.
To Next Page
