6-158 Designjet Z Series — Service Manual
Removal and Installation
25. Remove the Left Ink Supply Station bonding
cable.
26. Remove the right Side Plate of the Left Ink
Supply Station.
27. Carefully lift the Ink Supply Tubes out of the
printer.
After you reinstall the Ink
Supply Tubes, run the Purge
Tubes Service Utility before
performing the necessary
service calibrations. Refer to
Page
3-62
.
When you finish installing or replacing this component, you must perform the
necessary Service Calibrations. To find which calibrations you must perform,
Refer to page 6-8,
Service Calibration Guide to Removal and Installation
.
