6-164 Designjet Z Series — Service Manual
Removal and Installation
5. Remove one T-15 screw that secures the
Electronics Module to the Printer.
6. Remove one T-15 screw that secures the
Electronics Module to the Printer.
7. Remove two T-15 screws that secure the
Electronics Module to the Printer.
To Next Page
