T640 PIC/FPC Compatibility
The PIC/FPC compatibility matrixes lists the current PICs for T640 routers, both
standalone and connected to a T640 Matrix router unless otherwise noted, and the first
Junos OS Release in which the FPC supports the PIC. For example, Junos 7.6 is the first
release in which the T640-FPC1-E2 supports the ATM2 OC3/STM1 IQ, 2-port PIC.
•
PIC/FPC Compatibility (Type 1 FPCs and Type 1 PICs) on page 89
•
PIC/FPC Compatibility (Type 2 FPCs and Type 2 PICs) on page 90
•
PIC/FPC Compatibility (Type 3 FPCs and Type 3 PICs) on page 92
•
PIC/FPC Compatibility (Type 4 FPCs and Type 4 PICs) on page 93
PIC/FPC Compatibility (Type 1 FPCs and Type 1 PICs)
Table 47 on page 89 provides a PIC/FPC compatibility matrix for the current Type 1 PICs
for the T640 router and Type 1 FPCs.
Table 47: T640 PIC/FPC Compatibility Type 1
T640-FPC1-EST640-FPC1-E2T640-FPC1-EPIC Model NumberPIC
ATM2 IQ PICs
–7.47.4PB-4E3-ATM2ATM2 E3 IQ, 4-port
–7.67.6PB-2OC3-ATM2-MM
PB-2OC3-ATM2-SMIR
ATM2 OC3/STM1 IQ, 2-port
–8.08.0PB-1OC12-ATM2-MM
PB-1OC12-ATM2-SMIR
ATM2 OC12/ STM4 IQ, 1-port
Channelized IQ PICs
9.48.08.0PB-4CHDS3-QPPChDS3 IQ, 4-port
9.47.67.6PB-1CHOC3-SMIR-QPPChOC3 IQ, 1-port
9.47.57.5PB-1CHSTM1-SMIR-QPPChSTM1 IQ, 1-port
Channelized IQE PICs
9.49.3R29.3R2PB-4CHDS3-E3-IQE-BNCChDS3/E3 IQE, 4-port
9.59.59.5PB-1OCHE1-T1-IQE-RJ48ChE1/T1 IQE, 10-port
9.49.39.3PB-2CHOC3-STM1-IQE-SFPChOC3/STM1 IQE, 2-port
9.49.39.3PB-1CHOC12-STM4-IQE-SFPChOC12/STM4 IQE, 1-port
TI, DS3, E1, E3 PICs
89Copyright © 2017, Juniper Networks, Inc.
