CAUTION: Take care not to bend or otherwise damage the power
connector prongs.
7. Slide the FPC all the way into the card cage until you feel resistance.
8. Starting with the ejector handles on the FPC faceplate nearly horizontal, simultaneously
turn both ejector handles clockwise to seat the FPC.
9. If you are installing a Type 2 FPC or Type 3 FPC, tighten the screws inside the ejector
handles to secure the FPC. Do not overtighten them.
10. Repeat the procedure to reinstall each remaining FPC.
Figure 88: Reinstalling an FPC
Copyright © 2017, Juniper Networks, Inc.202
T640 Core Router Hardware Guide
