Example of calculating system thermal output:
Watts DC/0.293 = BTU/hr
6283/0.293 = 21,444 BTU/hr
Related
Documentation
T640 Power System Description on page 95•
• T640 DC Power System Electrical Specifications on page 125
• T640 DC Power Supply Electrical Specifications on page 126
• T640 General Electrical Safety Guidelines and Electrical Codes on page 529
T640 DC Power Distribution
Most sites distribute DC power through a main conduit that leads to frame-mounted DC
power distribution panels, one of which might be located at the top of the rack that
houses the router. A pair of cables (one input and one return) connects each set of
terminal studs to the power distribution panel.
NOTE: All inputs on the two-input 160-A DC power supply in slot PEM0 must
be powered by dedicated power feeds derived from feed A, and all inputs on
the two-input 160-A DC power supply in slot PEM1 must be powered by
dedicated power feeds derived from feed B. This configuration provides the
commonly deployed A/B feed redundancy for the system.
NOTE: INPUT 0 and INPUT 1 on the three-input 240-A DC power supply in
slot PEM0 must be powered by dedicated power feeds derived from feed A,
and INPUT 0 and INPUT 1 on the three-input 240-A DC power supply in slot
PEM1 must be powered by dedicated power feeds derived from feed B. This
configuration provides the commonly deployed A/B feed redundancy for the
system.
NOTE: All inputs on the four-input240-A DC powersupply in slotPEM0 must
be powered by dedicated power feeds derived from feed A, and all inputs on
the four-input 240-A DC power supply in slot PEM1 must be powered by
dedicated power feeds derived from feed B. This configuration provides the
commonly deployed A/B feed redundancy for the system.
NOTE: All inputs on the six-input DC power supply in slot PEM0 must be
powered by dedicated power feeds derived from feed A, and all inputs on
the six-input DC power supply in slot PEM1 must be powered by dedicated
power feeds derived from feed B. This configuration provides the commonly
deployed A/B feed redundancy for the system.
Copyright © 2017, Juniper Networks, Inc.130
