9. Grasp the Routing Engine by the ejector handles, and slide it about halfway out of the
chassis.
10. Place one of your hands underneath the Routing Engine to support it and slide it
completely out of the chassis.
11. Place the Routing Engine on the antistatic mat.
12. If you are not replacing the Routing Engine now, reinstall the Routing Engine cover
and tighten the screws on the corners of the cover to secure it to the chassis (see
“Reinstalling the Routing Engine Cover on page 318).
Figure 153: Removing the Routing Engine Cover
Figure 154: Removing a Routing Engine
Installing a T640 Routing Engine
To install a Routing Engine (see Figure 155 on page 320):
Copyright © 2017, Juniper Networks, Inc.318
T640 Core Router Hardware Guide
