CAUTION: Be sure to slide the CIP straight within the slot to avoid
damaging the connector pins on the front of the midplane.
Figure 117: Removing a CIP
Installing a T640 CIP
To install the CIP (see Figure 118 on page 270):
1. Attach an electrostatic discharge (ESD) grounding strap to your bare wrist, and connect
the strap to one of the ESD points on the chassis.
2. Grasp the CIP handle with one hand and hold the bottom edge of the CIP with the
other hand to support its weight.
Copyright © 2017, Juniper Networks, Inc.268
T640 Core Router Hardware Guide
