CAUTION: Eachthree-input 240-ADC powersupplyweighs approximately
25 lb (11.3 kg). Be prepared to support the full weight of the power supply
as you remove it from the router.
12. Place one hand underneath the power supply to support it, and slide it completely
out of the chassis.
WARNING: Do not touch the power connectors on the rear of the power
supply (see Figure 176on page 359). They can contain dangerousvoltages.
Figure 176: Rear of the Power Supply Showing Midplane Connectors
Figure 177: Removing a Three-Input 240-A DC Power Supply
359Copyright © 2017, Juniper Networks, Inc.
Chapter 29: Replacing Power System Components
