HD LED
The RE-600 Routing Engine boots from the storage media in this order: the PC Card (if
present), then the CompactFlash card (if present), then the hard disk.
Related
Documentation
T640 Hardware Component Overview on page 13•
• T640 Host Subsystem Description on page 35
• T640 Routing Engine Description on page 36
• T640 RE-600 LEDs on page 39
• Maintaining the T640 Routing Engines on page 448
T640 RE-600 LEDs
Table 12 on page 39 describes the functions of the HD LED.
Table 12: Routing Engine 600 LEDs
DescriptionStateColorLabel
Indicates activity on the hard drive.On steadily or
blinking
YellowHD
NOTE: The LEDs on the Routing Engine do not necessarily indicate
routing-related activity.
NOTE: The LEDs that report host module status (including Routing Engine
status) are on the craft interface rather than the Routing Engine faceplate.
Related
Documentation
T640 Host Subsystem Description on page 35•
• T640 Routing Engine Description on page 36
• T640 RE-600 Description on page 37
• T640 LED Overview on page 464
• Troubleshooting the T640 Host Subsystem on page 472
T640 RE-1600 Description
The RE-1600 Routing Engine boots from the storage media in this order: the PC Card in
SLOT 0 (if present), then the PC Card in SLOT 1 (if present), then the CompactFlash card
(if present), then the hard disk.
39Copyright © 2017, Juniper Networks, Inc.
Chapter 5: Host Subsystem Components and Descriptions
