Replacing the T640 Management Ethernet Cable
To replace the management Ethernet cable:
1. Press the tab on the connector and pull the connector straight out of the ETHERNET
port. Figure 121 on page 276 shows the connector.
2. Disconnect the cable from the network device.
3. Plug one end of the replacement cable into the appropriate ETHERNET port. The ports
labeled HOST 0 connect to the Routing Engine in the upper Routing Engine slot (RE0),
and the ports labeled HOST 1 connect to the Routing Engine in the lower Routing
Engine slot (RE1).
4. Plug the other end of the cable into the network device.
275Copyright © 2017, Juniper Networks, Inc.
Chapter 25: Replacing Chassis Components
