CAUTION: Do not let fiber-optic cable hang free from the connector. Do
not allow fastened loops of cable to dangle, which stresses the cable at
the fastening point.
3. Simultaneously pull the two releases on the cable management system. Lift it up and
outward to lock it in place to access the air filter.
4. Loosen the captive screws on the corners of the air filter faceplate.
5. Grasp the handles and pull the air filter straight out of the chassis.
6. Remove the filter element from the air filter frame (see Figure 125 on page 282).
Figure 124: Removing the Front Air Filter
Figure 125: Replacing the Front Filter Element
Copyright © 2017, Juniper Networks, Inc.282
T640 Core Router Hardware Guide
