1. Make sure that the voltage across the DC power source cable leads is 0 V and that
there is no chance that the cables might become active during installation.
CAUTION: You must ensure that power connections maintain the proper
polarity. The power source cables might be labeled (+) and (–) to indicate
their polarity. There is no standard color coding for DC power cables. The
color coding used by the external DC power source at your site determines
the color coding for the leads on the power cables that attach to the
terminal studs on each power supply.
2. Attach an electrostatic discharge (ESD) grounding strap to your bare wrist, and connect
the strap to one of the ESD points on the chassis.
3. Switch the circuit breakers on the power supply faceplate to the off position (O).
4. Using both hands, slide the power supply into the chassis until you feel resistance.
5. Twist the ejector handles at the upper corners of the power supply faceplate clockwise
until they stop.
6. Tighten the captive screws at the lower corners of the power supply faceplate to
secure the power supply in the chassis.
7. Remove the clear plastic cover protecting the terminal studs on the faceplate.
8. Remove the nut and washer from each power terminal stud. If no washers and nuts
are already installed, they should be in the accessory box.
9. Secure the cable lug on the DC power cable to the terminal stud, first with a washer,
then with a nut (see Figure 174 on page 356). Use a 7/16-in. (11 mm) nut driver or wrench
to tighten the nut (see Figure 173 on page 355). Apply between 23 lb-in. (2.6 Nm) and
25 lb-in. (2.8 Nm) of torque to each nut:
a. Secure each positive (+) DC source power cable lug to a RTN (return) terminal.
b. Secure each negative (–) DC source power cable lug to a –48V (input) terminal.
NOTE: All inputs on the two-input 160-A DC power supply in slot PEM0
must be powered by dedicated power feeds derived from feed A, and all
inputs on the two-input 160-A DC power supply in slot PEM1 must be
poweredbydedicated powerfeedsderivedfromfeedB. Thisconfiguration
provides the commonly deployed A/B feed redundancy for the system.
353Copyright © 2017, Juniper Networks, Inc.
Chapter 29: Replacing Power System Components
