102 Keysight InfiniiVision 4000 X-Series Oscilloscopes Programmer's Guide
4 Commands Quick Reference
Table 14 :EXTernal Trigger Commands Summary
Command Query Options and Query Returns
:EXTernal:BWLimit
<bwlimit> (see
page 384)
:EXTernal:BWLimit?
(see page 384)
<bwlimit> ::= {0 | OFF}
:EXTernal:PROBe
<attenuation> (see
page 385)
:EXTernal:PROBe? (see
page 385)
<attenuation> ::= probe
attenuation ratio in NR3 format
:EXTernal:RANGe
<range>[<suffix>]
(see page 386)
:EXTernal:RANGe? (see
page 386)
<range> ::= vertical full-scale
range value in NR3 format
<suffix> ::= {V | mV}
:EXTernal:UNITs
<units> (see page 387)
:EXTernal:UNITs? (see
page 387)
<units> ::= {VOLT | AMPere}
Table 15 :FUNCtion<m> Commands Summary
Command Query Options and Query Returns
:FUNCtion<m>:AVERage:
COUNt <count> (see
page 394)
:FUNCtion<m>:AVERage:
COUNt? (see page 394)
<count> ::= an integer from 2 to
65536 in NR1 format
<m> ::= 1 to (# math functions)
in NR1 format
:FUNCtion<m>:BUS:CLOC
k <source> (see
page 395)
:FUNCtion<m>:BUS:CLOC
k? (see page 395)
<source> ::= {CHANnel<n> |
DIGital<d>}
<n> ::= 1 to (# analog channels)
in NR1 format
<d> ::= 0 to (# digital channels
- 1) in NR1 format
<m> ::= 1 to (# math functions)
in NR1 format
:FUNCtion<m>:BUS:SLOP
e <slope> (see
page 396)
:FUNCtion<m>:BUS:SLOP
e? (see page 396)
<slope> ::= {NEGative | POSitive
| EITHer}
<m> ::= 1 to (# math functions)
in NR1 format
:FUNCtion<m>:BUS:YINC
rement <value> (see
page 397)
:FUNCtion<m>:BUS:YINC
rement? (see page 397)
<value> ::= value per bus code,
in NR3 format
<m> ::= 1 to (# math functions)
in NR1 format
:FUNCtion<m>:BUS:YORi
gin <value> (see
page 398)
:FUNCtion<m>:BUS:YORi
gin? (see page 398)
<value> ::= value at bus code =
0, in NR3 format
<m> ::= 1 to (# math functions)
in NR1 format
