Keysight Technologies InfiniiVision MSO-X 4022A

Commands Quick Reference 4
Keysight InfiniiVision 4000 X-Series Oscilloscopes Programmer's Guide 103
:FUNCtion<m>:BUS:YUNi
ts <units> (see
page 399)
:FUNCtion<m>:BUS:YUNi
ts? (see page 399)
<units> ::= {VOLT | AMPere |
NONE}
<m> ::= 1 to (# math functions)
in NR1 format
:FUNCtion<m>:CLEar
(see page 400)
n/a n/a
:FUNCtion<m>:DISPlay
{{0 | OFF} | {1 |
ON}} (see page 401)
:FUNCtion<m>:DISPlay?
(see page 401)
{0 | 1}
<m> ::= 1 to (# math functions)
in NR1 format
:FUNCtion<m>[:FFT]:CE
NTer <frequency> (see
page 402)
:FUNCtion<m>[:FFT]:CE
NTer? (see page 402)
<frequency> ::= the current
center frequency in NR3 format.
The range of legal values is from
-25 GHz to 25 GHz.
<m> ::= 1 to (# math functions)
in NR1 format
:FUNCtion<m>[:FFT]:FR
EQuency:STARt
<frequency> (see
page 403)
:FUNCtion<m>[:FFT]:FR
EQuency:STARt? (see
page 403)
<frequency> ::= the start
frequency in NR3 format.
<m> ::= 1 to (# math functions)
in NR1 format
:FUNCtion<m>[:FFT]:FR
EQuency:STOP
<frequency> (see
page 404)
:FUNCtion<m>[:FFT]:FR
EQuency:STOP? (see
page 404)
<frequency> ::= the stop
frequency in NR3 format.
<m> ::= 1 to (# math functions)
in NR1 format
:FUNCtion<m>[:FFT]:GA
TE <gating> (see
page 405)
:FUNCtion<m>[:FFT]:GA
TE? (see page 405)
<gating> ::= {NONE | ZOOM}
<m> ::= 1-4 in NR1 format
:FUNCtion<m>[:FFT]:PH
ASe:REFerence
<ref_point> (see
page 406)
:FUNCtion<m>[:FFT]:PH
ASe:REFerence? (see
page 406)
<ref_point> ::= {TRIGger |
DISPlay}
<m> ::= 1-4 in NR1 format
:FUNCtion<m>[:FFT]:SP
AN <span> (see
page 407)
:FUNCtion<m>[:FFT]:SP
AN? (see page 407)
<span> ::= the current frequency
span in NR3 format.
Legal values are 1 Hz to 100 GHz.
<m> ::= 1 to (# math functions)
in NR1 format
:FUNCtion<m>[:FFT]:VT
YPe <units> (see
page 408)
:FUNCtion<m>[:FFT]:VT
YPe? (see page 408)
<units> ::= {DECibel | VRMS} for
the FFT (magnitude) operation
<units> ::= {DEGRees | RADians}
for the FFTPhase operation
<m> ::= 1 to (# math functions)
in NR1 format
Table 15 :FUNCtion<m> Commands Summary (continued)
Command Query Options and Query Returns
