1272 Keysight InfiniiVision 4000 X-Series Oscilloscopes Programmer's Guide
35 :WGEN<w> Commands
Introduction to
:WGEN<w>
Commands
The :WGEN<w> subsystem provides commands to select the waveform generator
function and parameters.
:WGEN<w>:OUTPut:POLar
ity <polarity> (see
page 1304)
:WGEN<w>:OUTPut:POLar
ity? (see page 1304)
<polarity> ::= {NORMal |
INVerted}
<w> ::= 1 or 2 in NR1 format
:WGEN<w>:OUTPut:SINGl
e (see page 1305)
n/a n/a
:WGEN<w>:PERiod
<period> (see
page 1306)
:WGEN<w>:PERiod? (see
page 1306)
<period> ::= period in seconds in
NR3 format
<w> ::= 1 or 2 in NR1 format
:WGEN<w>:RST (see
page 1307)
n/a <w> ::= 1 or 2 in NR1 format
:WGEN<w>:TRACk {{0 |
OFF} | {1 | ON}} (see
page 1308)
:WGEN<w>:TRACk? (see
page 1308)
{0 | 1}
<w> ::= 1 or 2 in NR1 format
:WGEN<w>:TRACk:AMPLit
ude {{0 | OFF} | {1 |
ON}} (see page 1309)
:WGEN<w>:TRACk:AMPLit
ude? (see page 1309)
{0 | 1}
<w> ::= 1 or 2 in NR1 format
:WGEN<w>:TRACk:CSIGna
l (see page 1310)
n/a <w> ::= 1 or 2 in NR1 format
:WGEN<w>:TRACk:FREQue
ncy {{0 | OFF} | {1 |
ON}} (see page 1311)
:WGEN<w>:TRACk:FREQue
ncy? (see page 1311)
{0 | 1}
<w> ::= 1 or 2 in NR1 format
:WGEN<w>:TRACk:PHASe
<phase> (see
page 1312)
:WGEN<w>:TRACk:PHASe?
(see page 1312)
<w> ::= 1 or 2 in NR1 format
<phase> ::= -360 to +360 in NR1
format
:WGEN<w>:VOLTage
<amplitude> (see
page 1313)
:WGEN<w>:VOLTage?
(see page 1313)
<amplitude> ::= amplitude in
volts in NR3 format
<w> ::= 1 or 2 in NR1 format
:WGEN<w>:VOLTage:HIGH
<high> (see page 1314)
:WGEN<w>:VOLTage:HIGH
? (see page 1314)
<high> ::= high-level voltage in
volts, in NR3 format
<w> ::= 1 or 2 in NR1 format
:WGEN<w>:VOLTage:LOW
<low> (see page 1315)
:WGEN<w>:VOLTage:LOW?
(see page 1315
)
<low> ::= low-level voltage in
volts, in NR3 format
<w> ::= 1 or 2 in NR1 format
:WGEN<w>:VOLTage:OFFS
et <offset> (see
page 1316)
:WGEN<w>:VOLTage:OFFS
et? (see page 1316)
<offset> ::= offset in volts in
NR3 format
<w> ::= 1 or 2 in NR1 format
Table 159 :WGEN<w> Commands Summary (continued)
Command Query Options and Query Returns
