Keysight Technologies InfiniiVision MSO-X 4022A

Commands Quick Reference 4
Keysight InfiniiVision 4000 X-Series Oscilloscopes Programmer's Guide 153
:SBUS<n>:LIN:TRIGger:
ID <value> (see
page 882)
:SBUS<n>:LIN:TRIGger:
ID? (see page 882)
<value> ::= 7-bit integer in
decimal, <nondecimal>, or
<string> from 0-63 or 0x00-0x3f
<nondecimal> ::= #Hnn where n ::=
{0,..,9 | A,..,F} for hexadecimal
<nondecimal> ::= #Bnn...n where n
::= {0 | 1} for binary
<string> ::= "0xnn" where n ::=
{0,..,9 | A,..,F} for hexadecimal
:SBUS<n>:LIN:TRIGger:
PATTern:DATA <string>
(see page 883)
:SBUS<n>:LIN:TRIGger:
PATTern:DATA? (see
page 883)
<string> ::= "n" where n ::=
32-bit integer in unsigned
decimal when <base> = DECimal
<string> ::= "nn...n" where n ::=
{0 | 1 | X | $} when <base> =
BINary
<string> ::= "0xnn...n" where n
::= {0,..,9 | A,..,F | X | $}
when <base> = HEX
:SBUS<n>:LIN:TRIGger:
PATTern:DATA:LENGth
<length> (see
page 885)
:SBUS<n>:LIN:TRIGger:
PATTern:DATA:LENGth?
(see page 885)
<length> ::= integer from 1 to 8
in NR1 format
:SBUS<n>:LIN:TRIGger:
PATTern:FORMat <base>
(see page 886)
:SBUS<n>:LIN:TRIGger:
PATTern:FORMat? (see
page 886)
<base> ::= {BINary | HEX |
DECimal}
:SBUS<n>:LIN:TRIGger:
SYMBolic:FRAMe <name>
(see page 887)
:SBUS<n>:LIN:TRIGger:
SYMBolic:FRAMe? (see
page 887)
<name> ::= quoted ASCII string
:SBUS<n>:LIN:TRIGger:
SYMBolic:SIGNal
<name> (see page 888)
:SBUS<n>:LIN:TRIGger:
SYMBolic:SIGNal? (see
page 888)
<name> ::= quoted ASCII string
:SBUS<n>:LIN:TRIGger:
SYMBolic:VALue <data>
(see page 889)
:SBUS<n>:LIN:TRIGger:
SYMBolic:VALue? (see
page 889)
<data> ::= value in NR3 format
Table 33 :SBUS<n>:LIN Commands Summary (continued)
Command Query Options and Query Returns
Table 34 :SBUS<n>:M1553 Commands Summary
Command Query Options and Query Returns
:SBUS<n>:M1553:AUTose
tup (see page 891)
n/a n/a
:SBUS<n>:M1553:BASE
<base> (see page 892)
:SBUS<n>:M1553:BASE?
(see page 892)
<base> ::= {BINary | HEX}
