154 Keysight InfiniiVision 4000 X-Series Oscilloscopes Programmer's Guide
4 Commands Quick Reference
:SBUS<n>:M1553:SOURce
<source> (see
page 893)
:SBUS<n>:M1553:SOURce
? (see page 893)
<source> ::= {CHANnel<n>}
<n> ::= 1 to (# analog channels)
in NR1 format
:SBUS<n>:M1553:TRIGge
r:PATTern:DATA
<string> (see
page 894)
:SBUS<n>:M1553:TRIGge
r:PATTern:DATA? (see
page 894)
<string> ::= "nn...n" where n ::=
{0 | 1 | X}
:SBUS<n>:M1553:TRIGge
r:RTA <value> (see
page 895)
:SBUS<n>:M1553:TRIGge
r:RTA? (see page 895)
<value> ::= 5-bit integer in
decimal, <nondecimal>, or
<string> from 0-31
<nondecimal> ::= #Hnn where n ::=
{0,..,9|A,..,F}
<string> ::= "0xnn" where n::=
{0,..,9|A,..,F}
:SBUS<n>:M1553:TRIGge
r:TYPE <type> (see
page 896)
:SBUS<n>:M1553:TRIGge
r:TYPE? (see page 896)
<type> ::= {DSTArt | DSTOp |
CSTArt | CSTOp | RTA | PERRor |
SERRor | MERRor | RTA11}
Table 34 :SBUS<n>:M1553 Commands Summary (continued)
Command Query Options and Query Returns
Table 35 :SBUS<n>:SENT Commands Summary
Command Query Options and Query Returns
:SBUS<n>:SENT:CLOCk
<period> (see
page 900)
:SBUS<n>:SENT:CLOCk?
(see page 900)
<period> ::= the nominal clock
period (tick), from 1 us to 300
us, in NR3 format.
:SBUS<n>:SENT:CRC
<format> (see
page 901)
:SBUS<n>:SENT:CRC?
(see page 901)
<format> ::= {LEGacy |
RECommended}
:SBUS<n>:SENT:DISPlay
<base> (see page 902)
:SBUS<n>:SENT:DISPlay
? (see page 902)
<base> ::= {HEX | DECimal |
SYMBolic}
:SBUS<n>:SENT:FORMat
<decode> (see
page 904)
:SBUS<n>:SENT:FORMat?
(see page 904)
<decode> ::= {NIBBles | FSIGnal |
FSSerial | FESerial | SSERial |
ESERial}
:SBUS<n>:SENT:IDLE
<state> (see page 906)
:SBUS<n>:SENT:IDLE?
(see page 906)
<state> ::= {LOW | HIGH}
:SBUS<n>:SENT:LENGth
<#_nibbles> (see
page 907)
:SBUS<n>:SENT:LENGth?
(see page 907)
<#_nibbles> ::= from 1-6, in NR1
format.
:SBUS<n>:SENT:PPULse
{{0 | OFF} | {1 |
ON}} (see page 908)
:SBUS<n>:SENT:PPULse?
(see page 908)
{0 | 1}
